ほとんどのヴィンテージアメリカ製真空管アンプに標準適合

■測定値と仕様■
・製品測定値
Body Depth : 11.5 mm
Body Width : 24 mm
Bushing Length : 6.5 mm
Bushing Thread : 3/8"-32UNF
Hex Nut Thickness : 2.2 mm
Hex Nut Width : 12.6 mm
Insulation Resistance : ＞100 MΩ at 500VDC
Life : 15,000 cycles
Manual Soldering Max Temp for 3 sec. : 350 °C
Max. Working Voltage : 500V
Max Rotational Stopper Strength : 6Kgf
Operating (Useable) Temperature : -10 °C to +70 °C
Rated Wattage (Power) : 0.5W
Rotational Torque : 20-200 gf-cm
Shaft Diameter : 6.35 mm
Sliding Noise : ＜47 mV
Tap Residual Resistance : ?100 Ω
Taper : Linear
Tolerance : ±20%
Total Rotational Angle : 300° ±5°
Total Shaft Length : 15 mm
Washer I.D. : 9.7 mm
Washer O.D. : 16 mm
Washer Thickness : 0.4 mm
Withstand Voltage : 500 VAC for 1 min.
・パッケージ情報
Packaging Dimensions : 1.3 in. × 0.973 in. × 1.048 in.
Weight (Packaging) : 0.023 lbs.
